Upwall's fixed windows are non-operable, designed to maximize natural light and frame expansive, uninterrupted views. Built with high-performance, energy-efficient glass and slim, durable aluminum frames, they offer both insulation and modern aesthetics. Ideal for accent walls or pairing with operable windows, they bring clean, architectural style to any space.

Fixed Windows

APEX SERIES
Fixed Slim Aluminum Window

APEX SERIES
Fixed Standard Aluminum Window

  • Double or triple glass with Low-E & argon, warm edge space is availabl

  • · High quality, powder coated, aluminum finish

  • Design Wind Pressure: 3000Pa
    Ultimate Wind Pressure: 4500 Pa
    Water Resistance: 600Pa
    Sound Insulation: 33-40 dB
    U-Factor: 0.31 - 0.28
    Certifications: NFSC & CSA

  • Double or triple glass with Low-E & argon, warm edge space is availabl

  • · High quality, powder coated, aluminum finish

  • Design Wind Pressure: 3000Pa
    Ultimate Wind Pressure: 4500 Pa
    Water Resistance: 600Pa
    Sound Insulation: 33-40 dB
    U-Factor: 0.35 - 0.30
    Certifications: NFSC & CSA

VISTA SERIES
Fixed Vinyl Window

VISTA SERIES
Fixed Vinyl Angle Window

    • Sleek, narrow sight lines as slim as 1 7/16”.

    • High performance insulated and tempered glazing.

    • Custom grid and color options

  • · Architectural grade vinyl frame

  • Air Infiltration: 0.15 - 0.30
    Solar Heat Coefficient: 0.25
    Water Resistance: Up to 15
    OITC & STC: 28-35 & 26
    U-Value: 0.25
    Condensation Resistance: 0.15-0.30

    • Sleek, narrow sight lines as slim as 1 7/16”.

    • High performance insulated and tempered glazing.

    • Custom grid and color options

  • · Architectural grade vinyl frame

  • Air Infiltration: 0.15 - 0.30
    Solar Heat Coefficient: 0.25
    Water Resistance: Up to 15
    OITC & STC: 28-35 & 26
    U-Value: 0.25
    Condensation Resistance: 0.15-0.30

VISTA SERIES
Fixed Vinyl Corner Window

VISTA SERIES
Fixed Vinyl Bay Window

    • Sleek, narrow sight lines as slim as 1 7/16”.

    • High performance insulated and tempered glazing.

    • Custom grid and color options

  • · Architectural grade vinyl frame

  • Air Infiltration: 0.15 - 0.30
    Solar Heat Coefficient: 0.25
    Water Resistance: Up to 15
    OITC & STC: 28-35 & 26
    U-Value: 0.25
    Condensation Resistance: 0.15-0.30

    • Sleek, narrow sight lines as slim as 1 7/16”.

    • High performance insulated and tempered glazing.

    • Custom grid and color options

  • · Architectural grade vinyl frame

  • Air Infiltration: 0.15 - 0.30
    Solar Heat Coefficient: 0.25
    Water Resistance: Up to 15
    OITC & STC: 28-35 & 26
    U-Value: 0.25
    Condensation Resistance: 0.15-0.30
